Application Scenario: Special machine for the corrugated cardboard/box industry.
High-pressure compaction:
The pressure of the pressing plate can reach 4 tons, ensuring that the binding is tight and stable.
Electric paper protection mechanism:
Equipped with 4 electric corner protectors, compatible with cardboard of different sizes, automatically adding corner protection and pressing binding to protect the edges of the cardboard from damage.
| Item | Parameter |
|---|---|
| Applicable cargo dimensions | W(1000-1600)×H500-2300mm |
| Lance height | 350mm |
| Lance cross-sectional area | 30×50mm |
| Power | 3KW |
| Compressed air | 200L/min 0.4-0.6MPa |
| Tension force | 0-2500N |
| PET strap specification | 1206/1608 |
| Passable height | 2650mm (conveyor height + cargo height) |
| Machine weight | 2.3T |
| CT time | 50S (2 straps incl. infeed/outfeed) |
| Press plate pressure | 0-2T |
| Paper protector size | 100×100×5mm / 250×250×5mm |
| Paper protector capacity | 100pcs |
