Vertical Strapping System
Conveyor System
Application Scenario: Suitable for goods that require cross-type strapping.
Standard Rotary Table:
Supports cross-type strapping for more secure strapping.
High Efficiency Capacity:
Processing speed up to 30 pallets per hour.
Strap Feeding Mechanism (optional):
Reduces downtime and minimizes material waste.
2e76fc7194e78d68f2918af18484587e4f3580ff.jpg)
| Item | Parameter |
|---|---|
| Applicable cargo dimensions | L(800-1200)×W(800-1200)×H(500-1350)mm |
| Lance height | 600mm |
| Lance cross-sectional area | 30×50mm (for 19mm strap: 30×60mm) |
| Power | 2.2KW |
| Tension force | 0-2500N/0-3500N |
| PET strap specification | 1608/1910 |
| Column width | 2200mm |
| Passable height | 2150mm (cargo height + conveyor height) |
| Machine weight | 2T |
| CT time | 100S/pallet |
| Rotary table diameter | 2000mm (max) |
